Cluster Commands

Clusters are named logical groups of hosts. A group can contain one node, and groups can overlap. Save all nodes as the default and use smaller named groups when useful. Prefer cluster references over explicit host lists in everyday commands; see Recommended Cluster Setups.

The scheduler selects and orders eligible hosts for each job; the first selected host becomes its head node. See Schedulers & Placement for hardware constraints, reservations, and explicit layouts.

Terminal window
sparkrun cluster create <name> --hosts <ip1>,<ip2>,... [options]
OptionDescription
--hosts / -HComma-separated host list
--hosts-fileFile with hosts (one per line)
-d / --descriptionCluster description
--user / -uSSH username for this cluster
--cache-dirHuggingFace cache directory on cluster hosts (useful when control machine and cluster have different paths, e.g. macOS → Linux)
--transfer-modeResource transfer mode: auto, local, push, or delegated
--transfer-interfaceNetwork interface for transfers: auto, cx7, or mgmt
--schedulerPlacement scheduler (default occupancy-sparse). See Schedulers & Placement.
--max-gpu-mem-utilFraction of each accelerator’s memory treated as usable for placement
--executorPin the launch executor for this cluster
--executor-opt / -oPer-executor config, -o key=value (repeatable)
--defaultSet this cluster as the default after creating it
--offlineMake launches use existing artifacts by default; see Offline defaults
Terminal window
sparkrun cluster create mylab \
--hosts 10.24.11.13,10.24.11.14 \
--user dgxuser \
-d "2-node DGX Spark cluster"
# With transfer mode for external control machines
sparkrun cluster create mylab \
--hosts 10.24.11.13,10.24.11.14 \
--transfer-mode push

See Resource Transfer Modes for details on transfer mode options.

Terminal window
sparkrun cluster update <name> [options]

All options are the same as create. Only provided options are updated — omitted fields are left unchanged. Pass --user "" or --cache-dir "" to explicitly clear a value.

update additionally accepts:

OptionDescription
--add-hostAdd a host without restating the whole list (repeatable)
--remove-hostRemove a host (repeatable)
--topologySet the cluster’s network topology
--infer-hardwareProbe hosts and record detected accelerator metadata
--clear-executor-configDrop any stored per-executor config
--offline / --onlineEnable or remove the cluster’s offline launch default
Terminal window
sparkrun cluster update mylab --hosts 10.24.11.13,10.24.11.14,10.24.11.15
sparkrun cluster update mylab --add-host 10.24.11.15
sparkrun cluster update mylab --transfer-mode delegated
sparkrun cluster update mylab --user newuser
# Adopt the 0.3.x default placement on a cluster created by sparkrun 0.2.x
sparkrun cluster update mylab --scheduler occupancy-sparse

See Resource Transfer Modes for details on transfer mode options.

Terminal window
sparkrun cluster list

Shows all saved clusters with their hosts and descriptions. The default cluster is marked with *.

Terminal window
sparkrun cluster show <name>

Displays name, description, user, cache directory, transfer mode, default status, and all hosts.

Terminal window
sparkrun cluster delete <name>
sparkrun cluster delete <name> --force # skip confirmation prompt
Terminal window
sparkrun cluster inspect [name]

Shows the resolved cluster settings — transfer mode, transfer interface, topology, SSH user, and cache directories — and checks whether those cache directories actually exist on each remote host. Useful for diagnosing configuration, transfer, or permission problems without running a job.

Terminal window
sparkrun cluster import svd <path-to-.env>

Imports a spark-vllm-docker .env file into a sparkrun cluster, mapping CLUSTER_NODES to hosts, ETH_IF to fabric interfaces, and CONTAINER_* to env references. The env references are resolved from the file at launch time, so secrets stay out of the cluster YAML. Re-running syncs in place. Aliased as sparkrun cluster import eugr.

Terminal window
sparkrun cluster set-default <name>
sparkrun cluster unset-default
sparkrun cluster default # show current default

When a default cluster is set, commands like sparkrun run and sparkrun stop use it automatically without needing --cluster or --hosts.

Terminal window
sparkrun cluster status
sparkrun status # alias

Shows running sparkrun workloads, pending operations (downloads/distributions in progress), and idle hosts across the cluster. See Cluster Status for full details.

Example Docker workload output (addresses and image tags are illustrative):

$ sparkrun cluster status
Job: qwen3.5-35b-a3b-fp8-sglang (tp=2) (2 container(s))
node_0 10.24.11.13 (ib: 192.168.11.13) Up 35 seconds scitrera/dgx-spark-sglang:0.5.9-dev1-329817e2-t5
node_1 10.24.11.14 (ib: 192.168.11.14) Up 9 seconds scitrera/dgx-spark-sglang:0.5.9-dev1-329817e2-t5
logs: sparkrun logs qwen3.5-35b-a3b-fp8-sglang --hosts 10.24.11.13,10.24.11.14 --tp 2
stop: sparkrun stop qwen3.5-35b-a3b-fp8-sglang --hosts 10.24.11.13,10.24.11.14 --tp 2
Idle hosts (no sparkrun containers):
10.24.11.16
10.24.11.17
Total: 2 container(s) across 4 host(s)
Terminal window
sparkrun cluster monitor [options]

Live-monitor CPU, RAM, and GPU metrics across cluster hosts, with interactive workload log viewing. By default this launches a TUI; pass --simple for plain-text output or --json for telemetry samples. Press q on the main screen or Ctrl-C to stop.

Cluster monitor showing six hosts, sensor sparklines for the selected host, and colorized workload logs.
Host metrics, sensor history, and workload logs. Select the image for full size. Screenshot from PR #322.
OptionDescription
--hosts / -HComma-separated host list
--hosts-fileFile with hosts (one per line)
--clusterUse a saved cluster by name
--interval / -iSampling interval in seconds (default: 2)
--simpleUse plain-text output instead of TUI
--jsonEmit telemetry samples as JSON
--dry-run / -nShow what would be done
Terminal window
sparkrun cluster monitor --cluster mylab
sparkrun cluster monitor --cluster mylab --interval 5
sparkrun cluster monitor --cluster mylab --simple

Select a host to see its CPU and GPU identity, memory use, and recent sensor history. The detail panel uses compact sparklines for CPU/GPU utilization, temperatures, GPU power and clock, RAM, and network send/receive rates. The nv-monitor backend also supplies application/cache memory breakdowns when available. Unavailable metrics display - and are skipped in the history.

By default, the session retains up to 120 telemetry points per host, about four minutes at the default two-second interval. Collection continues while you view another host or workload logs; history starts when the monitor opens and is not persisted. Network rates use adaptive bits-per-second units in the TUI; JSON sample fields net_send_bytes_s and net_recv_bytes_s use bytes per second. The Bash backend sums non-loopback interfaces.

Set the per-host history capacity in config.yaml:

monitor:
history_points: 300 # About ten minutes at a two-second sampling interval

Use a positive integer; missing, invalid, or non-positive settings fall back to 120. Repeated reads of the same sample do not add points, so stalled telemetry does not appear as fresh flat-line readings. The window is bounded by sample count, not a guaranteed duration.

Applications can access the same session history through the Python monitoring API.

Select a host with Enter to open its workload list, then choose a workload with Enter or a mouse click to stream its logs. The viewer colorizes known runtime output and provides a fallback for other runtimes.

KeyAction in the log viewer
SpacePause/follow, or jump back to the live tail when scrolled away
1, 2, 3Select container, node, or whole-workload cluster scope where available
/Search with a regular expression
n, bNext or previous search match
hToggle search-term highlighting
cToggle log colorization
lToggle line wrapping
dExport logs to a local file
Escape or qReturn from the log viewer

Scroll upward to page older retained history. Cluster scope combines the selected workload’s sources in arrival order while following. Searching operates on loaded history, and paging depends on the logs still retained by the backend. Once the search input is focused, typing / inserts a literal slash into your expression.

The export dialog lets you choose scope, path, and whether to overwrite an existing file. It reads complete retained logs for that scope, not just the visible buffer. Cancelled or failed exports discard partial output. Viewing, exporting, or closing logs leaves inference running. For scripts, use sparkrun logs or the Log Streaming API.
